Name: ATA6561-GAQW-N
Brand: Microchip Technology
SKU: ATA6561-GAQW-N
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology ATA6561-GAQW-N

Part No.:: ATA6561-GAQW-N

Manufacturer:: Microchip Technology

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: ATA6561-GAQW-N.pdf

Description:: IC TRANSCEIVER 1/1 8SO

In Stock:: 3131

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ATA6561-GAQW-N Specifications

Package/Case:
8-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q100, Functional Safety (FuSa)
ProductStatus:
Active
Type:
Transceiver
Protocol:
CAN
NumberofDrivers/Receivers:
1/1
Duplex:
-
ReceiverHysteresis:
120 mV
DataRate:
5Mbps
Voltage-Supply:
4.5V ~ 5.5V
OperatingTemperature:
-40°C ~ 150°C (TJ)
MountingType:
Surface Mount
