Microchip Technology AT91SAM7SE512B-AU

Part No.:: AT91SAM7SE512B-AU

Manufacturer:: Microchip Technology

Package:: 128-LQFP

Datasheet:: AT91SAM7SE512B-AU.pdf

Description:: IC MCU 16/32B 512KB FLSH 128LQFP

In Stock:: 2771

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AT91SAM7SE512B-AU Specifications

Package/Case:
128-LQFP
Packaging:
Tray
Series:
SAM7SE
RoHS:
RoHS
Speed:
55MHz
RAM Size:
32K x 8
Core Size:
16/32-Bit
EEPROM Size:
-
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
EBI/EMI, I²C, SPI, SSC, UART/USART, USB
Mounting Type:
Surface Mount
Number of I/O:
88
Core Processor:
ARM7®
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
512KB (512K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
