Microchip Technology AT90CAN64-16MUR

Part No.:: AT90CAN64-16MUR

Manufacturer:: Microchip Technology

Package:: 64-VFQFN Exposed Pad

Datasheet:: AT90CAN64-16MUR.pdf

Description:: IC MCU 8BIT 64KB FLASH 64QFN

In Stock:: 2320

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AT90CAN64-16MUR Specifications

Package/Case:
64-VFQFN Exposed Pad
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
AVR® 90CAN
RoHS:
RoHS
Speed:
16MHz
RAM Size:
4K x 8
Core Size:
8-Bit
EEPROM Size:
2K x 8
Part Status:
Active
Peripherals:
Brown-out Detect/Reset, POR, PWM, WDT
Connectivity:
CANbus, EBI/EMI, I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
53
Core Processor:
AVR
Data Converters:
A/D 8x10b
Oscillator Type:
Internal
Program Memory Size:
64KB (64K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

AT90CAN64-16MUR this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AT90CAN64-16MUR price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AT90CAN64-16MUR to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AT90CAN64-16MUR information

Views：

AT90CAN64-16MUR Typical application Circuitry

The AT90CAN64-16MUR serves as an advanced 8-bit AVR microcontroller, known for its low-power consumption and high-speed performance. Designed by Microchip Technology, the chip is furnished with 64 KB of ISP Flash, 2 KB EEPROM, and 2 KB SRAM. It features a specialized CAN (Controller Area Network) controller, adding to its broad applicability.

Use Cases to Consider

1. Automotive Control Systems

2. Smart Grids

3. Home Automation

4. Medical Instrumentation

Highlighted Parameters

- Core: 8-bit AVR architecture

- Clock Speed: Max 16 MHz

- Voltage Range: 4.5V - 5.5V

- I/O Pin Count: 52 pins

- Integrated Peripherals: CAN, USART, SPI, ADC

Circuit Design for Smart Grids Application

Materials Required

- AT90CAN64-16MUR microcontroller unit (MCU)

- A pair of 22pF ceramic capacitors

- A 16MHz crystal oscillator

- Two 10kΩ pull-up resistors

- CAN transceiver chip (e.g., MCP2551)

- 5V regulated DC power supply

Pin Connections in Detail

1. Power Supply Handling

VCC (Pins 10 & 30): Wire these to your 5V DC source.

GND (Pins 11 & 31): Connect to the circuit's common ground.

2. Clock Source Setup

XTAL1 (Pin 12) and XTAL2 (Pin 13): Link to a 16MHz crystal. Solder 22pF capacitors between each of these pins and the ground to dampen oscillations.

3. Setting up CAN Interface

PD2 (Pin 21) should connect to the TXD terminal of your CAN transceiver. Similarly, PD3 (Pin 22) connects to RXD on the same transceiver.

4. General-purpose I/O Configuration

Pins PC0-PC7 (Pins 23-30): These pins serve dual roles as digital or analog input/output. If used as digital inputs, 10kΩ pull-up resistors may be useful.

5. USART for Debugging

PD0 (Pin 14) and PD1 (Pin 15): These pins are meant for UART connections and can be linked to a computer through a UART-to-USB converter for debugging.

Considerations While Designing the Circuit

1. Voltage Regulation: Keep the supply voltage between 4.5V and 5.5V to prevent potential damage to the AT90CAN64-16MUR.

2. Clock Accuracy: Use a high-quality 16MHz oscillator to maintain precise timing on the AT90CAN64-16MUR.

3. Network Configurations: Properly terminate the CAN bus and adhere to standardized timing settings to maintain communication integrity.

4. Electromagnetic Compatibility: Since Smart Grids are susceptible to interference, ensure that your AT90CAN64-16MUR circuit is well-shielded and grounded.

By being mindful of these factors, the AT90CAN64-16MUR can function optimally within a Smart Grid environment, leveraging its various features for efficient operations.
