Adesto Technologies AT45DB641E-SHN-T

Part No.:: AT45DB641E-SHN-T

Manufacturer:: Adesto Technologies

Package:: 8-SOIC (0.209, 5.30mm Width)

Datasheet:: AT45DB641E-SHN-T.pdf

Description:: IC FLASH 64MBIT SPI 85MHZ 8SOIC

In Stock:: 3566

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AT45DB641E-SHN-T Specifications

Package/Case:
8-SOIC (0.209, 5.30mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
FLASH
Technology:
FLASH
MemorySize:
64Mb (264 Bytes x 32K pages)
MemoryInterface:
SPI
ClockFrequency:
85 MHz
WriteCycleTime-WordPage:
8µs, 5ms
AccessTime:
-
Voltage-Supply:
1.7V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TC)
MountingType:
Surface Mount
