Microchip Technology AT28C64B-15JU-T

Part No.:: AT28C64B-15JU-T

Manufacturer:: Microchip Technology

Package:: 32-LCC (J-Lead)

Datasheet:: AT28C64B-15JU-T.pdf

Description:: IC EEPROM 64KBIT PARALLEL 32PLCC

In Stock:: 3376

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AT28C64B-15JU-T Specifications

Package/Case:
32-LCC (J-Lead)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
EEPROM
Technology:
EEPROM
MemorySize:
64Kb (8K x 8)
MemoryInterface:
Parallel
ClockFrequency:
-
WriteCycleTime-WordPage:
10ms
AccessTime:
150 ns
Voltage-Supply:
4.5V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C (TC)
MountingType:
Surface Mount
