Microchip Technology AT27C512R-45PU

Part No.:: AT27C512R-45PU

Manufacturer:: Microchip Technology

Package:: 28-DIP (0.600, 15.24mm)

Datasheet:: AT27C512R-45PU.pdf

Description:: IC EPROM 512KBIT PARALLEL 28DIP

In Stock:: 2206

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AT27C512R-45PU Specifications

Package/Case:
28-DIP (0.600, 15.24mm)
Packaging:
Tube
Series:
-
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
EPROM
Technology:
EPROM - OTP
MemorySize:
512Kb (64K x 8)
MemoryInterface:
Parallel
ClockFrequency:
-
WriteCycleTime-WordPage:
-
AccessTime:
45 ns
Voltage-Supply:
4.5V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C (TC)
MountingType:
Through Hole
