Name: AT27C256R-45JU-T
Brand: Microchip Technology
SKU: AT27C256R-45JU-T
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Microchip Technology AT27C256R-45JU-T

Part No.:: AT27C256R-45JU-T

Manufacturer:: Microchip Technology

Package:: 32-LCC (J-Lead)

Datasheet:: AT27C256R-45JU-T.pdf

Description:: IC EPROM 256KBIT PARALLEL 32PLCC

In Stock:: 3910

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AT27C256R-45JU-T Specifications

Package/Case:
32-LCC (J-Lead)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
EPROM
Technology:
EPROM - OTP
MemorySize:
256Kb (32K x 8)
MemoryInterface:
Parallel
ClockFrequency:
-
WriteCycleTime-WordPage:
-
AccessTime:
45 ns
Voltage-Supply:
4.5V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C (TC)
MountingType:
Surface Mount
