Microchip Technology AT27C010-70JU-T

Part No.:: AT27C010-70JU-T

Manufacturer:: Microchip Technology

Package:: 32-LCC (J-Lead)

Datasheet:: AT27C010-70JU-T.pdf

Description:: IC EPROM 1MBIT PARALLEL 32PLCC

In Stock:: 3091

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AT27C010-70JU-T Specifications

Package/Case:
32-LCC (J-Lead)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
MemoryType:
Non-Volatile
MemoryFormat:
EPROM
Technology:
EPROM - OTP
MemorySize:
1Mb (128K x 8)
MemoryInterface:
Parallel
ClockFrequency:
-
WriteCycleTime-WordPage:
-
AccessTime:
70 ns
Voltage-Supply:
4.5V ~ 5.5V
OperatingTemperature:
-40°C ~ 85°C (TC)
MountingType:
Surface Mount
