Alliance Memory, Inc. AS4C32M16SB-7TIN

Part No.:: AS4C32M16SB-7TIN

Manufacturer:: Alliance Memory, Inc.

Package:: 54-TSOP (0.400, 10.16mm Width)

Datasheet:: AS4C32M16SB-7TIN.pdf

Description:: IC DRAM 512MBIT PAR 54TSOP II

In Stock:: 3816

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AS4C32M16SB-7TIN Specifications

Package/Case:
54-TSOP (0.400, 10.16mm Width)
Packaging:
Tray
Series:
-
ProductStatus:
Active
MemoryType:
Volatile
MemoryFormat:
DRAM
Technology:
SDRAM
MemorySize:
512Mb (32M x 16)
MemoryInterface:
Parallel
ClockFrequency:
143 MHz
WriteCycleTime-WordPage:
14ns
AccessTime:
5.4 ns
Voltage-Supply:
3V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
