Name: ADUC812BSZ-REEL
Brand: Analog Devices Inc.
SKU: ADUC812BSZ-REEL
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. ADUC812BSZ-REEL

Part No.:: ADUC812BSZ-REEL

Manufacturer:: Analog Devices Inc.

Package:: 52-QFP

Datasheet:: ADUC812BSZ-REEL.pdf

Description:: IC MCU 8BIT 8KB FLASH 52MQFP

In Stock:: 2802

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADUC812BSZ-REEL Specifications

Package/Case:
52-QFP
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
MicroConverter® ADuC8xx
RoHS:
RoHS
Speed:
16MHz
RAM Size:
256 x 8
Core Size:
8-Bit
EEPROM Size:
640 x 8
Part Status:
Active
Peripherals:
PSM, Temp Sensor, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
34
Core Processor:
8052
Data Converters:
A/D 8x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
8KB (8K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)
