Analog Devices Inc. ADUC812BSZ

Part No.:: ADUC812BSZ

Manufacturer:: Analog Devices Inc.

Package:: 52-QFP

Datasheet:: ADUC812BSZ.pdf

Description:: IC MCU 8BIT 8KB FLASH 52MQFP

In Stock:: 3721

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADUC812BSZ Specifications

Package/Case:
52-QFP
Packaging:
Tray
Series:
MicroConverter® ADuC8xx
RoHS:
RoHS
Speed:
16MHz
RAM Size:
256 x 8
Core Size:
8-Bit
EEPROM Size:
640 x 8
Part Status:
Active
Peripherals:
PSM, Temp Sensor, WDT
Connectivity:
I²C, SPI, UART/USART
Mounting Type:
Surface Mount
Number of I/O:
34
Core Processor:
8052
Data Converters:
A/D 8x12b; D/A 2x12b
Oscillator Type:
Internal
Program Memory Size:
8KB (8K x 8)
Program Memory Type:
FLASH
Operating Temperature:
-40°C ~ 85°C (TA)

ADUC812BSZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADUC812BSZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADUC812BSZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADUC812BSZ information

Views：

ADUC812BSZ Typical application Circuitry

The ADUC812BSZ is a complete smart transducer front end integrated circuit from Analog Devices. It includes a high accuracy 12-bit Analog-to-Digital Converter (ADC), 8K Bytes Flash/EE PROM, and an 8051 compatible microcontroller on a single chip. Here is a simplified explanation of an application circuit for the ADUC812BSZ:

1. Power Supply: The ADUC812BSZ has multiple power pins (AVDD, DVDD, AGND, DGND) for separate analog and digital supply lines. This separation is crucial for noise reduction in sensitive analog operations. Typically, it requires a supply voltage of 4.5V to 5.5V. Placing decoupling capacitors close to these power pins is a good practice to filter out any noise in the power supply lines.
2. Clock Circuit: The ADUC812BSZ has an on-chip oscillator that drives the 8051 core and peripherals. It can be configured for external clocking or crystal operation using the XTAL1 and XTAL2 pins.
3. Reset Circuit: The RST pin is typically connected to a reset switch or a reset controller circuit that ensures the proper startup of the IC. This pin is active high.
4. ADC Inputs: The ADUC812BSZ has 8 multiplexed ADC inputs that can be used for interfacing with various analog sensors or signals. These inputs are labeled as VIN0 to VIN7.
5. DAC Outputs: The ADUC812BSZ has two 12-bit DAC outputs labeled as DAC0OUT and DAC1OUT. These can be used to output analog signals.
6. Digital I/O: The 8051 microcontroller provides a number of digital I/O pins which can be used for interfacing with other digital devices.
7. Serial I/O: The ADUC812BSZ provides a serial I/O (UART) interface for communication with other devices or a host PC.
8. I2C Interface: This device provides an I2C interface for communication with other I2C compatible devices.
9. SPI Interface: The SPI interface can be used for high-speed synchronous serial communication with other devices.
10. In-System Programming/Debugging: The ADUC812BSZ supports in-system programming of the on-chip flash memory over the serial interface. This can be achieved through the UART pins (TXD and RXD).
This is a simplified description and may not include all the necessary components for your specific application. It is always recommended to consult the device datasheet and reference design guidelines when designing the application circuit. The specific design can change significantly based on the system requirements where the ADUC812BSZ is being used.
