Analog Devices Inc. ADG804YRMZ

Part No.:: ADG804YRMZ

Manufacturer:: Analog Devices Inc.

Package:: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)

Datasheet:: ADG804YRMZ.pdf

Description:: IC MULTIPLEXER 4X1 10MSOP

In Stock:: 3055

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADG804YRMZ Specifications

Package/Case:
10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
SwitchCircuit:
SP4T
Multiplexer/DemultiplexerCircuit:
4:1
NumberofCircuits:
1
On-StateResistance(Max):
650mOhm
Channel-to-ChannelMatching(ΔRon):
40mOhm
Voltage-SupplySingle(V+):
1.65V ~ 3.6V
Voltage-SupplyDual(V±):
-
SwitchTime(TonToff)(Max):
29ns, 6ns
-3dbBandwidth:
33MHz
ChargeInjection:
28pC
ChannelCapacitance(CS(off)CD(off)):
24pF, 105pF
Current-Leakage(IS(off))(Max):
2nA
Crosstalk:
-75dB @ 100kHz
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
