Analog Devices Inc. ADG734BRUZ

Part No.:: ADG734BRUZ

Manufacturer:: Analog Devices Inc.

Package:: 20-TSSOP (0.173, 4.40mm Width)

Datasheet:

Description:: IC SWITCH QUAD SPDT 20TSSOP

In Stock:: 3244

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADG734BRUZ Specifications

Package/Case:
20-TSSOP (0.173, 4.40mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
SwitchCircuit:
SPDT
Multiplexer/DemultiplexerCircuit:
2:1
NumberofCircuits:
4
On-StateResistance(Max):
4.5Ohm
Channel-to-ChannelMatching(ΔRon):
-
Voltage-SupplySingle(V+):
1.8V ~ 5.5V
Voltage-SupplyDual(V±):
±2.5V
SwitchTime(TonToff)(Max):
21ns, 10ns (Typ)
-3dbBandwidth:
200MHz
ChargeInjection:
5pC
ChannelCapacitance(CS(off)CD(off)):
11pF
Current-Leakage(IS(off))(Max):
100pA
Crosstalk:
-67dB @ 1MHz
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

ADG734BRUZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADG734BRUZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADG734BRUZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADG734BRUZ information

Views：

ADG734BRUZ Typical application Circuitry

ADG734BRUZ

ADG734BRUZ is a low voltage, low on-resistance, quad SPDT (single pole double throw) switch that operates with a single supply voltage range from 1.8 V to 5.5 V. This makes the ADG734BRUZ suitable for battery-powered applications and portable devices.

Applications of ADG734BRUZ:

1. Audio and video signal routing

2. Data acquisition systems

3. Test and measurement equipment

4. Communications systems

Parameter Features of ADG734BRUZ:

1. Single supply voltage range: 1.8 V to 5.5 V

2. On-resistance: 4.5 ohms typical

3. Bandwidth: 200 MHz

4. 4 SPDT switches

Example Application Circuit for Audio Signal Routing:

1. Power Supply Connection:

- Connect the VDD pin (pin 16) to a 3.3V power supply.

- Connect the VSS pin (pin 8) to the system's ground.

2. Input and Output Connection:

- Connect the audio input signals to the S1A to S4A pins (pins 1 to 4).

- Connect the S1B to S4B pins (pins 5 to 9) to the input of the audio processing module.

- Connect the output pin (D, pin 10) to the input of the audio processing module.

3. Control Connection:

- Connect the digital control signals to the A0 to A1 pins (pins 14 to 15) to select the desired input channel.

- Connect the EN pin (pin 13) to a logic low level to enable the switch.

Design Considerations:

- Ensure that the power supply voltage is within the specified range for ADG734BRUZ.

- Consider the effects of on-resistance and capacitance on the audio input signals.

- Configure the digital control signals appropriately to select the desired input channels for audio routing.

In conclusion, ADG734BRUZ is a versatile chip that can be used in a variety of applications requiring precision switching of analog signals. When designing a circuit with this chip, it is important to consider the power supply requirements, the effects of on-resistance and capacitance, and the proper configuration of control signals. By following these guidelines, you can effectively utilize the quad SPDT switches in an audio signal routing application, ensuring high-performance and reliable operation.
