Analog Devices Inc. ADG709BRUZ

Part No.:: ADG709BRUZ

Manufacturer:: Analog Devices Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:

Description:: IC MULTIPLEXER DUAL 4X1 16TSSOP

In Stock:: 3835

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADG709BRUZ Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Bulk,Tube
Series:
-
ProductStatus:
Active
SwitchCircuit:
SP4T
Multiplexer/DemultiplexerCircuit:
4:1
NumberofCircuits:
2
On-StateResistance(Max):
4.5Ohm
Channel-to-ChannelMatching(ΔRon):
400mOhm
Voltage-SupplySingle(V+):
1.8V ~ 5.5V
Voltage-SupplyDual(V±):
±2.5V
SwitchTime(TonToff)(Max):
14ns, 8ns (Typ)
-3dbBandwidth:
55MHz
ChargeInjection:
3pC
ChannelCapacitance(CS(off)CD(off)):
13pF, 42pF
Current-Leakage(IS(off))(Max):
10pA (Typ)
Crosstalk:
-80dB @ 1MHz
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount

ADG709BRUZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADG709BRUZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADG709BRUZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADG709BRUZ information

Views：

ADG709BRUZ Typical application Circuitry

The ADG709BRUZ is a monolithic CMOS IC featuring a 4-channel, single-pole, single-throw (SPST) switch. Manufactured by Analog Devices, it's used in applications like data acquisition systems, communication systems, and relay replacements. The ADG709BRUZ can be connected to a circuit in the following general manner:

1. Power Supply: The positive and negative power supply rails should be linked to the VDD and GND pins, respectively. The ADG709BRUZ can operate from a single supply of 1.8V to 5.5V. A decoupling capacitor is typically used near these pins to filter out any noise or sudden changes in voltage.
2. Digital Inputs: The A0 and A1 pins are digital control inputs that select one of the four switches to close. These pins should be driven by logic signals (either 0V or VDD).
3. Analog Inputs/Outputs: The Sx and Dx pins are the source and drain terminals of the switches, respectively. Depending on the logic level applied to the control inputs (A0, A1), one of the Sx pins may be connected to its associated Dx pin.
4. Enable Input: The EN pin is used to enable or disable all switches. No matter how the A0 and A1 inputs are configured, all switches are open when the EN pin is driven low. The A0 and A1 inputs control the switch states when EN is high.
5. Ground Connection: The system ground should be linked to the GND pin.
The ADG709BRUZ does not require any external components for standard operation. However, based on your specific application needs, additional components may be necessary.
Always refer to the ADG709BRUZ datasheet and application notes for detailed specifications, performance characteristics, and any potential limitations or precautions to be taken into consideration while designing your circuit.
