Analog Devices Inc. ADG707BRUZ-REEL7

Part No.:: ADG707BRUZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 28-TSSOP (0.173, 4.40mm Width)

Datasheet:: ADG707BRUZ-REEL7.pdf

Description:: IC MULTIPLEXER DUAL 8X1 28TSSOP

In Stock:: 2799

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADG707BRUZ-REEL7 Specifications

Package/Case:
28-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
SwitchCircuit:
-
Multiplexer/DemultiplexerCircuit:
8:1
NumberofCircuits:
2
On-StateResistance(Max):
4.5Ohm
Channel-to-ChannelMatching(ΔRon):
-
Voltage-SupplySingle(V+):
1.8V ~ 5.5V
Voltage-SupplyDual(V±):
±2.5V
SwitchTime(TonToff)(Max):
32ns, 16ns (Typ)
-3dbBandwidth:
36MHz
ChargeInjection:
8pC
ChannelCapacitance(CS(off)CD(off)):
13pF, 90pF
Current-Leakage(IS(off))(Max):
100pA
Crosstalk:
-80dB @ 1MHz
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

ADG707BRUZ-REEL7 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADG707BRUZ-REEL7 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADG707BRUZ-REEL7 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADG707BRUZ-REEL7 information

Views：

ADG707BRUZ-REEL7 Typical application Circuitry

ADG707BRUZ-REEL7

The ADG707BRUZ-REEL7, a distinguished member of Analog Devices' multiplexer series, epitomizes precision and versatility in the realm of signal routing. Engineered for optimal performance in analog and digital signal management, this device seamlessly integrates into a myriad of electronic systems, offering a solution for applications requiring high-speed, low-voltage operations. Its design is tailored to facilitate the precise selection of analog signals, thereby enhancing the efficiency and reliability of data acquisition systems, communication devices, and audio processing units.

1. Series Overview and Key Features: As part of the illustrious ADG707 series, the ADG707BRUZ-REEL7 is designed for CMOS (Complementary Metal-Oxide-Semiconductor) technology, ensuring low power consumption and high-speed signal processing. This 8-channel multiplexer/demultiplexer functions with dual or single supply operation, making it adaptable to various operational voltages and enhancing its compatibility with diverse electronic environments.

2. Pin Configuration and Circuit Integration: Critical to harnessing the ADG707BRUZ-REEL7's capabilities is the accurate connection of its 24 pins, which include power supply (VDD), ground (GND), digital control inputs (S1, S2, S3), enable (EN) pin, and the eight analog inputs/outputs (D, S0-S7). The VDD pin powers the device, while the GND pin serves as the circuit's electrical ground. Control inputs S1 to S3 are used to select the active channel, enabling precise control over which analog signal is routed through the multiplexer. The EN pin, when activated, enables the device; otherwise, it places the multiplexer in a high-impedance state, effectively isolating it from the circuit.

3. Signal Integrity and Low Crosstalk: The ADG707BRUZ-REEL7 excels in maintaining the integrity of the analog signal, minimizing crosstalk and ensuring that the signal fidelity is preserved across all channels. This performance is pivotal for applications requiring accurate and clean signal transmission, such as in medical instrumentation and high-end audio equipment.

4. Efficient Power Management and Low On-Resistance: Featuring an innovative design, the ADG707BRUZ-REEL7 boasts low on-resistance, reducing power dissipation and facilitating efficient operation. This characteristic is particularly beneficial in battery-operated devices, where power efficiency is critical. Additionally, the multiplexer's ability to operate with low voltage differentials between the source and drain extends its application range to systems with limited power resources.

5. Packaging and Application Flexibility: The ADG707BRUZ-REEL7 is supplied in a TSSOP (Thin Shrink Small Outline Package), optimizing space on the printed circuit board (PCB) without compromising thermal performance. This packaging is instrumental for designers working on compact devices or where board space is at a premium.

In summary, the ADG707BRUZ-REEL7 represents a convergence of Analog Devices' commitment to innovation, precision, and versatility in signal processing technology. Its comprehensive design, which caters to efficient pin configuration, signal integrity, power management, and compact packaging, positions the ADG707BRUZ-REEL7 as an essential component for modern electronic systems requiring meticulous control over multiple analog inputs and outputs.
