Analog Devices Inc. ADG704BRMZ-REEL7

Part No.:: ADG704BRMZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)

Datasheet:: ADG704BRMZ-REEL7.pdf

Description:: IC MULTIPLEXER 4X1 10USOIC

In Stock:: 2121

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADG704BRMZ-REEL7 Specifications

Package/Case:
10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
SwitchCircuit:
SP4T
Multiplexer/DemultiplexerCircuit:
4:1
NumberofCircuits:
1
On-StateResistance(Max):
4Ohm
Channel-to-ChannelMatching(ΔRon):
-
Voltage-SupplySingle(V+):
1.8V ~ 5.5V
Voltage-SupplyDual(V±):
-
SwitchTime(TonToff)(Max):
14ns, 6ns (Typ)
-3dbBandwidth:
200MHz
ChargeInjection:
3pC
ChannelCapacitance(CS(off)CD(off)):
9pF, 37pF
Current-Leakage(IS(off))(Max):
100pA
Crosstalk:
-82dB @ 1MHz
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

ADG704BRMZ-REEL7 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADG704BRMZ-REEL7 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADG704BRMZ-REEL7 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADG704BRMZ-REEL7 information

Views：

ADG704BRMZ-REEL7 Typical application Circuitry

ADG704BRMZ-REEL7

ADG704BRMZ-REEL7 is a 4:1 multiplexer with a serial interface that operates from a 1.8 V to 5.5 V power supply. It can be used to route one of its four input channels to a common output based on the logic state of two address pins.

Applications of ADG704BRMZ-REEL7 include:

- Data acquisition systems

- Medical devices

- Communication systems

- Audio and video signal routing

Parameter Features of ADG704BRMZ-REEL7 include:

- Single supply operation: 1.8 V to 5.5 V

- Low on-resistance: typically 4 ohms

- Low charge injection: 0.6 pC

- Serial interface for control

Example Application Circuit for Audio Signal Routing in a Multimedia System:

1. Power Connection:

- Connect VDD (pin 8) to a 3.3V power supply.

- Connect GND (pin 5) to the system's ground.

2. Audio Input Connection:

- Connect the audio signals to input channels S1 to S4 (pins 1 to 4).

3. Speaker Connection:

- Connect the common output (D, pin 6) to the speaker's input.

4. Control Connections:

- Connect SCLK (Serial Clock, pin 7) and SDI (Serial Data Input, pin 9) to the microcontroller for serial communication.

- Connect A0 (Address 0, pin 10) and A1 (Address 1, pin 11) to the microcontroller.

5. Enable Connection:

- Connect /EN (Enable, pin 12) to a digital control signal to enable or disable the multiplexer.

Design Considerations:

- Ensure that the power supply voltage is within the specified range for ADG704BRMZ-REEL7.

- Pay attention to impedance matching between the audio sources, the multiplexer, and the speaker.

- Consider the effects of on-resistance and charge injection on the audio signal quality.

- Properly configure the serial interface to ensure effective communication between the multiplexer and the microcontroller.

In summary, ADG704BRMZ-REEL7 is an excellent choice for applications that require the routing of multiple signals to a single destination, such as audio signal routing in a multimedia system. Careful attention must be paid to power supply voltage, impedance matching, and the possible effects of on-resistance and charge injection on signal quality. Additionally, the serial interface must be configured correctly to enable efficient communication between the multiplexer and the microcontroller.
