Name: ADG704BRMZ-REEL
Brand: Analog Devices Inc.
SKU: ADG704BRMZ-REEL
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. ADG704BRMZ-REEL

Part No.:: ADG704BRMZ-REEL

Manufacturer:: Analog Devices Inc.

Package:: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)

Datasheet:: ADG704BRMZ-REEL.pdf

Description:: IC MULTIPLEXER 4X1 10USOIC

In Stock:: 3194

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADG704BRMZ-REEL Specifications

Package/Case:
10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
-
ProductStatus:
Active
SwitchCircuit:
SP4T
Multiplexer/DemultiplexerCircuit:
4:1
NumberofCircuits:
1
On-StateResistance(Max):
4Ohm
Channel-to-ChannelMatching(ΔRon):
-
Voltage-SupplySingle(V+):
1.8V ~ 5.5V
Voltage-SupplyDual(V±):
-
SwitchTime(TonToff)(Max):
14ns, 6ns (Typ)
-3dbBandwidth:
200MHz
ChargeInjection:
3pC
ChannelCapacitance(CS(off)CD(off)):
9pF, 37pF
Current-Leakage(IS(off))(Max):
100pA
Crosstalk:
-82dB @ 1MHz
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
