Analog Devices Inc. ADG621BRMZ-REEL

Part No.:: ADG621BRMZ-REEL

Manufacturer:: Analog Devices Inc.

Package:: 10-TFSOP, 10-MSOP (0.118, 3.00mm Width)

Datasheet:: ADG621BRMZ-REEL.pdf

Description:: IC SWITCH DUAL SPST 10MSOP

In Stock:: 3906

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADG621BRMZ-REEL Specifications

Package/Case:
10-TFSOP, 10-MSOP (0.118, 3.00mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
SwitchCircuit:
SPST - NO
Multiplexer/DemultiplexerCircuit:
1:1
NumberofCircuits:
2
On-StateResistance(Max):
5.5Ohm
Channel-to-ChannelMatching(ΔRon):
250mOhm
Voltage-SupplySingle(V+):
2.7V ~ 5.5V
Voltage-SupplyDual(V±):
±2.7V ~ 5.5V
SwitchTime(TonToff)(Max):
120ns, 70ns
-3dbBandwidth:
230MHz
ChargeInjection:
110pC
ChannelCapacitance(CS(off)CD(off)):
20pF, 20pF
Current-Leakage(IS(off))(Max):
250pA
Crosstalk:
-90dB @ 1MHz
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

ADG621BRMZ-REEL this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADG621BRMZ-REEL price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADG621BRMZ-REEL to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADG621BRMZ-REEL information

Views：

ADG621BRMZ-REEL Typical application Circuitry

The ADG621BRMZ-REEL functions as a CMOS dual single-pole, single-throw (SPST) switch. It is well-suited for battery-powered, portable instruments, thanks to its ultra-low power consumption and fast switching speed.

Application Scenarios for ADG621BRMZ-REEL

You can deploy this chip in:

- Battery-powered devices

- Audio signal routing

- Data acquisition systems

- Communications circuits

Technical Features of ADG621BRMZ-REEL

- Supply Voltage Range: +2 V to +12 V or ±2 V to ±6 V

- On-Resistance: 0.4 Ohm (max)

- Switching Speed: t_ON = 20 ns; t_OFF = 15 ns

- Bandwidth: 180 MHz

Designing a Circuit in an Audio Signal Routing System

Components Required:

- ADG621BRMZ-REEL Dual SPST Switch

- Audio source

- Audio amplifier

- Microcontroller

- Power supply

Detailed Connection Guide

Power Supplies

- Power Setup: Apply +5V to VDD (Pin 8) and connect VSS (Pin 5) to ground.

Connecting Audio Source

- Source Linkage: Attach the audio source's left and right channel outputs to Pin 1 (D1) and Pin 2 (D2), which are the two data inputs.

Connecting to Audio Amplifier

- Amplifier Interface: Hook up the audio amplifier inputs to Pin 3 (S1) and Pin 6 (S2), which are the switch outputs.

Control Logic

- Logic Connection: The IN1 (Pin 4) and IN2 (Pin 7) control pins should interface with the microcontroller's GPIO pins to govern the switching behavior.

Signal Ground

- Grounding: Connect the audio source, the amplifier, and the ADG621BRMZ-REEL to a common ground to minimize noise.

Design Considerations with ADG621BRMZ-REEL

1. Voltage Levels: Make sure to stay within the specified voltage range to avoid damaging the ADG621BRMZ-REEL.

2. Switching Time: This chip offers fast switching, but you should still consider its speed in your application to ensure optimal performance.

3. Noise Handling: Keep the layout well-grounded to minimize noise, especially in sensitive audio applications.

4. Heat Dissipation: Even though ADG621BRMZ-REEL is a low-power device, verify that your design accounts for any potential heat dissipation requirements in closed environments.

5. Signal Integrity: Use shielded cables and proper grounding techniques to maintain signal integrity in your audio application.

In summary, the ADG621BRMZ-REEL provides an efficient, low-power option for audio signal routing with high-speed switching capabilities. It's crucial to pay attention to power, noise, and switching speed when incorporating this chip into your designs.
