Analog Devices Inc. ADG619BRTZ-REEL7

Part No.:: ADG619BRTZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: SOT-23-8

Datasheet:

Description:: IC SWITCH SPDT SOT23-8

In Stock:: 3472

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADG619BRTZ-REEL7 Specifications

Package/Case:
SOT-23-8
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
SwitchCircuit:
SPDT
Multiplexer/DemultiplexerCircuit:
2:1
NumberofCircuits:
1
On-StateResistance(Max):
6.5Ohm
Channel-to-ChannelMatching(ΔRon):
700mOhm
Voltage-SupplySingle(V+):
2.7V ~ 5.5V
Voltage-SupplyDual(V±):
±2.7V ~ 5.5V
SwitchTime(TonToff)(Max):
120ns, 75ns
-3dbBandwidth:
190MHz
ChargeInjection:
110pC
ChannelCapacitance(CS(off)CD(off)):
25pF
Current-Leakage(IS(off))(Max):
250pA
Crosstalk:
-67dB @ 1MHz
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount

ADG619BRTZ-REEL7 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADG619BRTZ-REEL7 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADG619BRTZ-REEL7 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADG619BRTZ-REEL7 information

Views：

ADG619BRTZ-REEL7 Typical application Circuitry

ADG619BRTZ-REEL7

The ADG619BRTZ-REEL7 is a CMOS, low-voltage, single-pole double-throw (SPDT) switch from Analog Devices, available in a tape and reel format for automated assembly processes.

Application Scenarios

The ADG619BRTZ-REEL7 is ideal for use in precision analog signal routing, where its low on-resistance and low distortion are critical.Because of its broad operating voltage range and low power consumption, it can also be utilized in battery-powered devices.

Parameter Features

- SPDT Configuration: Provides flexibility in signal routing with one input and two selectable outputs, or vice versa.

- Low On-Resistance: Offers the least distortion and loss of signal.

- Wide Supply Voltage Range: Operating between +1.8V and +5.5V, this voltage range is appropriate for a range of power sources. - Fast Switching Times: Enables quick transition between signal paths.

Application Example: Signal Routing in a Portable Device

Designing a signal routing circuit in a portable device using the ADG619BRTZ-REEL7 involves several detailed steps to ensure efficient and accurate operation. Here's a detailed explanation:

- Power Supply Connection: Connect a 3.3V supply to the V+ pin (Pin 5) of the ADG619BRTZ-REEL7. This voltage level is common in portable electronics, balancing power efficiency with performance.

- Ground Connection: Join Pin 2 (GND) to the apparatus's ground. To minimize noise and ensure reliable operation, a strong ground connection is necessary.

- Signal Input/Output: For signal routing, connect the source signal to the COM pin (Pin 3). Depending on the application, this pin can function as an input or an output. The two target signals or devices should be connected to the NO (Normally Open, Pin 1) and NC (Normally Closed, Pin 6) pins. These connections determine the signal path based on the state of the switch.

- Control Logic: Apply a digital control signal to the IN pin (Pin 4) to toggle the switch state. This signal can be driven by a microcontroller or logic circuit, depending on the application requirements. The NO and NC connections are chosen by the logic level that is applied to this pin.

- Decoupling Capacitor: Place a decoupling capacitor (e.g., 0.1μF) near the V+ pin to filter out power supply noise, ensuring clean operation.

- Considerations for Minimizing Crosstalk: Keep the signal paths as short as possible and physically separate the control lines from the signal lines to reduce crosstalk and preserve signal integrity.

When integrating the ADG619BRTZ-REEL7 into a portable device, it's crucial to consider the power supply stability, control signal integrity, physical layout for minimizing crosstalk, and the impact of on-resistance on the signal path. Proper attention to these factors will exploit the low on-resistance, fast switching, and wide operating voltage range of the ADG619BRTZ-REEL7 to achieve efficient and accurate signal routing in portable electronic applications.
