Analog Devices Inc. ADG409BRZ-REEL

Part No.:: ADG409BRZ-REEL

Manufacturer:: Analog Devices Inc.

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: ADG409BRZ-REEL.pdf

Description:: IC MULTIPLEXER DUAL 4X1 16SOIC

In Stock:: 3001

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADG409BRZ-REEL Specifications

Package/Case:
16-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
SwitchCircuit:
SP4T
Multiplexer/DemultiplexerCircuit:
4:1
NumberofCircuits:
2
On-StateResistance(Max):
100Ohm
Channel-to-ChannelMatching(ΔRon):
15Ohm (Max)
Voltage-SupplySingle(V+):
12V
Voltage-SupplyDual(V±):
±15V
SwitchTime(TonToff)(Max):
-
-3dbBandwidth:
-
ChargeInjection:
20pC
ChannelCapacitance(CS(off)CD(off)):
11pF, 20pF
Current-Leakage(IS(off))(Max):
500pA
Crosstalk:
-85dB @ 100kHz
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
