Name: ADG1612BRUZ-REEL7
Brand: Analog Devices Inc.
SKU: ADG1612BRUZ-REEL7
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. ADG1612BRUZ-REEL7

Part No.:: ADG1612BRUZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: ADG1612BRUZ-REEL7.pdf

Description:: IC SWITCH QUAD SPST 16TSSOP

In Stock:: 3783

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADG1612BRUZ-REEL7 Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
SwitchCircuit:
SPST - NO
Multiplexer/DemultiplexerCircuit:
1:1
NumberofCircuits:
4
On-StateResistance(Max):
1.1Ohm
Channel-to-ChannelMatching(ΔRon):
30mOhm
Voltage-SupplySingle(V+):
3.3V ~ 16V
Voltage-SupplyDual(V±):
±3.3V ~ 8V
SwitchTime(TonToff)(Max):
156ns, 87ns
-3dbBandwidth:
38MHz
ChargeInjection:
170pC
ChannelCapacitance(CS(off)CD(off)):
60pF, 60pF
Current-Leakage(IS(off))(Max):
300pA
Crosstalk:
-110dB @ 1MHz
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount

ADG1612BRUZ-REEL7 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including ADG1612BRUZ-REEL7 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for ADG1612BRUZ-REEL7 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

ADG1612BRUZ-REEL7 information

Views：

ADG1612BRUZ-REEL7 Typical application Circuitry

ADG1612BRUZ-REEL7

The ADG1612BRUZ-REEL7 is a robust, quad single-pole single-throw (SPST) switch from Analog Devices, designed for use in applications requiring efficient and reliable switching of analog signals.

Application Scenarios

The ADG1612BRUZ-REEL7 is particularly useful in data acquisition systems, sample-and-hold circuits, communication systems, and any application that requires precise control over signal routing. Its ability to handle significant current levels while maintaining low on-resistance makes it suitable for both AC and DC signal switching.

Parameter Features

- Quad SPST Configuration: Provides four independent switching channels.

- Low On-Resistance: Ensures minimal signal attenuation.

- Wide Supply Voltage Range: Supports operations from +4.5V to +16.5V.

- Fast Switching Speed: Enhances performance in applications requiring rapid signal routing changes.

Application Example: Sample-and-Hold Circuit

Incorporating the ADG1612BRUZ-REEL7 into a sample-and-hold circuit involves careful planning to ensure optimal performance. Here's how to connect and configure the device:

- Power Supply Connection: Connect a +15V supply to the VDD pin (Pin 24) of the ADG1612BRUZ-REEL7. This provides the necessary operating voltage for the device.

- Grounding: Attach the GND pin (Pin 12) to the circuit's ground. A robust ground connection is crucial for minimizing noise and ensuring stable operation.

- Signal Input Connections: Connect the analog signals to be sampled to the source pins (S1-S4) of the ADG1612BRUZ-REEL7 (Pins 5, 8, 11, and 14). These pins will route the signals to the sample-and-hold capacitors.

- Output to Capacitors: Connect the drain pins (D1-D4) (Pins 6, 9, 12, and 15) to the sample-and-hold capacitors. When the switch is closed, the signal is held on the capacitor, effectively "sampling" the input signal.

- Control Logic: Apply digital control signals to the logic control pins (IN1-IN4) (Pins 1, 2, 3, and 4) to selectively open or close the switches. These control signals, typically driven by a microcontroller or digital logic circuit, enable precise timing for signal sampling.

- Decoupling Capacitor: Place a decoupling capacitor near the VDD pin to filter out any supply voltage noise, ensuring that the ADG1612BRUZ-REEL7 operates smoothly.

- Signal Integrity: To preserve signal integrity, keep the trace lengths short and well-shielded, especially in environments with significant electrical noise.

When designing with the ADG1612BRUZ-REEL7 in a sample-and-hold application, it's essential to consider the timing of control signals, the quality of the power supply, and the layout of the PCB to minimize noise and signal distortion. Proper attention to these factors will leverage the fast switching and low on-resistance of the ADG1612BRUZ-REEL7 to achieve high-performance signal sampling and holding.
