Name: ADG1411YRUZ
Brand: Analog Devices Inc.
SKU: ADG1411YRUZ
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. ADG1411YRUZ

Part No.:: ADG1411YRUZ

Manufacturer:: Analog Devices Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: ADG1411YRUZ.pdf

Description:: IC SWITCH QUAD SPST 16TSSOP

In Stock:: 3824

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADG1411YRUZ Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
SwitchCircuit:
SPST - NC
Multiplexer/DemultiplexerCircuit:
1:1
NumberofCircuits:
4
On-StateResistance(Max):
1.8Ohm
Channel-to-ChannelMatching(ΔRon):
100mOhm
Voltage-SupplySingle(V+):
5V ~ 16.5V
Voltage-SupplyDual(V±):
±4.5V ~ 16.5V
SwitchTime(TonToff)(Max):
150ns, 120ns
-3dbBandwidth:
170MHz
ChargeInjection:
-20pC
ChannelCapacitance(CS(off)CD(off)):
23pF, 23pF
Current-Leakage(IS(off))(Max):
550pA
Crosstalk:
-100dB @ 1MHz
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
