Name: ADE7932ARIZ-RL
Brand: Analog Devices Inc.
SKU: ADE7932ARIZ-RL
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. ADE7932ARIZ-RL

Part No.:: ADE7932ARIZ-RL

Manufacturer:: Analog Devices Inc.

Package:: 20-SOIC (0.295, 7.50mm Width)

Datasheet:

Description:: IC ADC/ENERGY MEAS 20SOIC

In Stock:: 3116

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ADE7932ARIZ-RL Specifications

Package/Case:
20-SOIC (0.295, 7.50mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Type:
ADC, Energy Measurement
NumberofChannels:
3
Resolution(Bits):
-
SamplingRate(PerSecond):
-
DataInterface:
I²C, SPI
VoltageSupplySource:
Single Supply
Voltage-Supply:
3.3V ~ 10V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
