Name: AD9214BRS-RL105
Brand: Analog Devices Inc.
SKU: AD9214BRS-RL105
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. AD9214BRS-RL105

Part No.:: AD9214BRS-RL105

Manufacturer:: Analog Devices Inc.

Package:: 28-SSOP (0.209, 5.30mm Width)

Datasheet:: AD9214BRS-RL105.pdf

Description:: IC ADC 10BIT PIPELINED 28SSOP

In Stock:: 1490

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD9214BRS-RL105 Specifications

Packaging:
Tape & Reel (TR),Bulk
Series:
-
Product Status:
Obsolete
Number of Bits:
10
Sampling Rate(PerSecond):
105M
Number of Inputs:
1
Input Type:
Differential, Single Ended
Data Interface:
Parallel
Configuration:
S/H-ADC
Ratio-S/H:ADC:
1:1
Number of A/D Converters:
1
Architecture:
Pipelined
Reference Type:
Internal
Voltage-Supply Analog:
2.7V ~ 3.6V
Voltage-Supply Digital:
2.7V ~ 3.6V
Features:
-
Operating Temperature:
-40°C ~ 85°C
