Analog Devices Inc. AD8210YRZ-REEL7

Part No.:: AD8210YRZ-REEL7

Manufacturer:: Analog Devices Inc.

Package:: 8-SOIC (0.154, 3.90mm Width)

Datasheet:: AD8210YRZ-REEL7.pdf

Description:: IC CURRENT MONITOR 0.5% 8SOIC

In Stock:: 265

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD8210YRZ-REEL7 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
-
ProductStatus:
Active
Function:
Current Monitor
SensingMethod:
High/Low-Side
Accuracy:
±0.7%
Voltage-Input:
-2V ~ 65V
Current-Output:
5mA
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
