Name: AD7891ASZ-1
Brand: Analog Devices Inc.
SKU: AD7891ASZ-1
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. AD7891ASZ-1

Part No.:: AD7891ASZ-1

Manufacturer:: Analog Devices Inc.

Package:: 44-QFP

Datasheet:: AD7891ASZ-1.pdf

Description:: IC DAS 12BIT 500K 44MQFP

In Stock:: 2832

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7891ASZ-1 Specifications

Package/Case:
44-QFP
Packaging:
Bulk,Tray
Series:
-
ProductStatus:
Active
Type:
Data Acquisition System (DAS)
NumberofChannels:
8
Resolution(Bits):
12 b
SamplingRate(PerSecond):
500k
DataInterface:
Serial, Parallel
VoltageSupplySource:
Single Supply
Voltage-Supply:
5V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
