Analog Devices Inc. AD7874BRZ

Part No.:: AD7874BRZ

Manufacturer:: Analog Devices Inc.

Package:: 28-SOIC (0.295, 7.50mm Width)

Datasheet:: AD7874BRZ.pdf

Description:: IC DAS 12BIT 116K 28SOIC

In Stock:: 3204

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7874BRZ Specifications

Package/Case:
28-SOIC (0.295, 7.50mm Width)
Packaging:
Bulk,Tube
Series:
-
ProductStatus:
Active
Type:
Data Acquisition System (DAS)
NumberofChannels:
4
Resolution(Bits):
12 b
SamplingRate(PerSecond):
116k
DataInterface:
Parallel
VoltageSupplySource:
Dual ±
Voltage-Supply:
±5V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
