Name: AD7147A-1ACBZ-RL
Brand: Analog Devices Inc.
SKU: AD7147A-1ACBZ-RL
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Analog Devices Inc. AD7147A-1ACBZ-RL

Part No.:: AD7147A-1ACBZ-RL

Manufacturer:: Analog Devices Inc.

Package:: 25-UFBGA, WLCSP

Datasheet:: AD7147A-1ACBZ-RL.pdf

Description:: IC CAP TO DGT 16BIT 250K 25WLCSP

In Stock:: 2887

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD7147A-1ACBZ-RL Specifications

Package/Case:
25-UFBGA, WLCSP
Packaging:
Tape & Reel (TR)
Series:
CapTouch™
ProductStatus:
Obsolete
Type:
Capacitance-to-Digital Converter
NumberofChannels:
13
Resolution(Bits):
16 b
SamplingRate(PerSecond):
250k
DataInterface:
I²C, Serial
VoltageSupplySource:
Single Supply
Voltage-Supply:
2.6V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C
MountingType:
Surface Mount
