Analog Devices Inc. AD592ANZ

Part No.:: AD592ANZ

Manufacturer:: Analog Devices Inc.

Package:: TO-226-3, TO-92-3 (TO-226AA)

Datasheet:: AD592ANZ.pdf

Description:: SENSOR ANALOG -25C-105C TO92-3

In Stock:: 893

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD592ANZ Specifications

Packaging:
Bulk
Series:
-
ProductStatus:
Active
SensorType:
Analog, Local
SensingTemperature-Local:
-25°C ~ 105°C
SensingTemperature-Remote:
-
OutputType:
Analog Current
Voltage-Supply:
4V ~ 30V
Resolution:
-
Features:
-
Accuracy-Highest(Lowest):
±2.5°C
TestCondition:
25°C
OperatingTemperature:
-25°C ~ 105°C
MountingType:
Through Hole

AD592ANZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD592ANZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD592ANZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD592ANZ information

Views：

AD592ANZ Typical application Circuitry Schematics

The AD592ANZ is a temperature transducer from Analog Devices. A proportional output current to absolute temperature is generated by the two-terminal integrated circuit temperature transducer. By passing a current that is directly proportional to absolute temperature (K), the device functions as a high impedance constant current regulator. The AD592ANZ can give typical accuracies of 1 °C at room temperature and 3 °C over the entire temperature range of 25 °C to +105 °C without the need for any external calibration or trimming. Here is a detailed step-by-step method to connect this sensor:

1.Supply Voltage: The AD592ANZ has two terminals, an anode (+) and a cathode (-). Anode (pin 1) should be connected to your power supply's positive terminal. Ensure the voltage does not exceed the device's maximum rated voltage (approximately 30V).

2. Load Resistor: Connect a load resistor (R_load) between the cathode (pin 2) and ground. This resistor is used to convert the output current from the AD592ANZ into a voltage that can be easily measured. The required output voltage determines the resistor's resistance. For example, if you want a voltage range of 0-5V, and since the AD592ANZ provides 1uA per degree Kelvin (1uA/K), a 5 k? resistor would give a voltage range of approximately 1.375 to 1.873V for the temperature range of 25 °C to 105 °C.

3. Microcontroller/ADC: If you're using a microcontroller or ADC to read the output voltage, connect the cathode side of the load resistor to the input pin of your microcontroller's ADC. Ensure that the ADC reference voltage is higher than the expected output voltage to get accurate readings.

4. Ground: Finally, connect the ground of your power supply to the common ground of the microcontroller/ADC.

Remember that the AD592ANZ output current is linear with temperature but is not linear with the output voltage across the load resistor because of the inherent logarithmic V-I relationship of semiconductors. When converting the ADC readings to temperature in your software, be sure to apply the correct conversion factor. In addition, always check your specific data sheet for any particular concerns or details about the device you're using. This is only a general overview; your unique application or situation might call for a different strategy.
