Analog Devices Inc. AD5592RBRUZ-RL7

Part No.:: AD5592RBRUZ-RL7

Manufacturer:: Analog Devices Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: AD5592RBRUZ-RL7.pdf

Description:: IC 12BT OCTAL SPI DAC/ADC ONCHIP

In Stock:: 3421

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD5592RBRUZ-RL7 Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR)
Series:
-
ProductStatus:
Active
Type:
ADC, DAC
NumberofChannels:
8
Resolution(Bits):
12 b
SamplingRate(PerSecond):
400k
DataInterface:
SPI
VoltageSupplySource:
Single Supply
Voltage-Supply:
2.7V ~ 5.5V
OperatingTemperature:
-40°C ~ 105°C
MountingType:
Surface Mount

AD5592RBRUZ-RL7 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD5592RBRUZ-RL7 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD5592RBRUZ-RL7 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD5592RBRUZ-RL7 information

Views：

AD5592RBRUZ-RL7 Typical application Circuitry

AD5592RBRUZ-RL7

The AD5592RBRUZ-RL7 is an integrated circuit that combines the functionality of an 8-channel configurable analog-to-digital converter (ADC), digital-to-analog converter (DAC), and digital I/O in a single compact package. Application Scenarios

A practical application for the AD5592RBRUZ-RL7 is in a smart industrial sensor interface where it can read various analog sensor outputs, control actuators based on sensor inputs, and communicate with a central processing unit or microcontroller.

Parameter Features

Key features of AD5592RBRUZ-RL7 include:

- 8-Channel Configurable I/O: Offers versatility in handling multiple input and output configurations with ADC, DAC, or digital I/O capabilities across its channels.

- 12-bit ADC and DAC Resolution: Ensures high precision in analog signal reading and output generation.

- Low Power Consumption: Perfect for battery-powered and energy-efficient applications.

- SPI Interface: Provides a high-speed serial interface for communication with microcontrollers or processors.

Specific Circuit Connection - Smart Industrial Sensor Interface

To incorporate AD5592RBRUZ-RL7 into a smart industrial sensor interface, follow this detailed connection guide:

- Power Supply and Grounding: Connect VDD (pin 16) to a regulated +2.7V to +5.5V power source. Attach GND (pin 9) to the system's ground. Accurate operation depends on a consistent and clean power source.

- Configurable I/O Pins for Analog Input: Select any of the I/O pins (pins 1-8) for connecting analog sensors. Configure these pins as ADC inputs via SPI commands to read sensor data. Use short and shielded cables to minimize noise and interference in the analog signals.

- Digital Output for Actuator Control: Configure other I/O pins as digital outputs to control actuators or relay modules based on processed sensor data. This involves setting the corresponding pins through SPI commands to represent the desired output states.

- SPI Communication Setup: Connect SCLK (pin 15) to the microcontroller's SPI clock, SDI (pin 14) to SPI MOSI (Master Out Slave In), and SDO (pin 13) to SPI MISO (Master In Slave Out) for serial data exchange. SYNC (pin 10) must be connected to an available GPIO on the microcontroller to manage the communication session with the AD5592RBRZ-RL7.

Design Considerations

When designing with AD5592RBRUZ-RL7, address the following:

- I/O Configuration Planning: Decide in advance how each I/O pin will be used (ADC, DAC, or digital I/O) and configure them accordingly at system startup via SPI.

- Signal Integrity for Analog Inputs: Implement best practices for PCB layout to preserve signal integrity, including using separate ground planes for analog and digital sections if possible.

- Power Supply Quality: To reduce noise and guarantee a smooth power supply to the AD5592RBRUZ-RL7, use decoupling capacitors close to the power supply pins.

- Thermal Management: Although AD5592RBRUZ-RL7 is designed for low power consumption, consider the thermal environment, especially in tightly packed industrial settings. Proper ventilation or heat sinking may be necessary depending on the application.

Incorporating AD5592RBRUZ-RL7 into a smart industrial sensor interface with careful attention to these design principles will result in a highly efficient, versatile, and accurate system capable of interfacing with a variety of sensors and actuators, enhancing automation and monitoring capabilities.
