Analog Devices Inc. AD5592RBRUZ

Part No.:: AD5592RBRUZ

Manufacturer:: Analog Devices Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: AD5592RBRUZ.pdf

Description:: IC ADC/DAC 12BIT 400K 16TSSOP

In Stock:: 2690

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD5592RBRUZ Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Tube
Series:
-
ProductStatus:
Active
Type:
ADC, DAC
NumberofChannels:
8
Resolution(Bits):
12 b
SamplingRate(PerSecond):
400k
DataInterface:
SPI
VoltageSupplySource:
Single Supply
Voltage-Supply:
2.7V ~ 5.5V
OperatingTemperature:
-40°C ~ 105°C
MountingType:
Surface Mount

AD5592RBRUZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD5592RBRUZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD5592RBRUZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD5592RBRUZ information

Views：

AD5592RBRUZ Typical application Circuitry

AD5592RBRUZ

The AD5592RBRUZ is a highly versatile, multi-channel I/O device that integrates analog-to-digital converters (ADCs), digital-to-analog converters (DACs), and digital I/O on a single chip. It is designed for applications where space and power efficiency are critical, making it ideal for portable devices, sensor interfacing, and control systems in industrial, automotive, and medical applications.

Application Scenarios

A typical application for the AD5592RBRUZ is in sensor data acquisition and control systems, where it can read various analog signals, convert them to digital for processing, and control external devices based on computational outcomes.

Parameter Features

AD5592RBRUZ is notable for its:

- Multi-Channel I/O: Offers eight configurable I/O channels that can function as ADC inputs, DAC outputs, or digital I/O, providing flexibility in interfacing with various types of signals and devices.

- High Resolution: Includes 12-bit ADCs and DACs, offering high precision for both input signal measurement and output signal control.

- Low Power Consumption: Perfect for energy-saving or battery-operated applications.

- Compact Form Factor: Available in a small, 16-lead TSSOP package, optimizing space on PCBs.

Specific Circuit Connection - Sensor Data Acquisition System

Integrating AD5592RBRUZ into a sensor data acquisition system requires careful planning around the device's multi-functional I/O channels and communication interface. Here's a detailed circuit connection guide:

- Power Supply and Grounding: Connect the VDD pin (pin 16) to a +2.7V to +5.5V power supply and the GND pin (pin 9) to the system ground. Stable power and proper grounding are essential to minimize noise and ensure accurate ADC readings and DAC outputs.

- Analog Input Configuration: For ADC functionality, connect analog sensors (e.g., temperature, pressure) to any of the configurable I/O pins (pins 1-8). Configuring these pins as ADC inputs through software allows the AD5592RBRUZ to read analog sensor data.

- Digital Output Configuration: To drive external devices, configure one or more of the I/O pins as digital outputs. This setup can be used to control relays, LEDs, or other digital interfaces based on the sensor data processed by the system.

- Serial Communication Interface: To communicate with a microcontroller or CPU, use the SPI interface. This involves connecting the SCLK (pin 15), SDI (pin 14), and SDO (pin 13) pins of the AD5592RBRUZ to the corresponding SPI pins on the microcontroller, along with the SYNC pin (pin 10) to govern the communication timing.

Design Considerations

When designing circuits with AD5592RBRUZ, consider the following:

- I/O Configuration: Properly plan the configuration of the I/O pins based on the application's requirements for ADC, DAC, and digital I/O functionalities. The configuration is done via SPI commands at startup.

- Signal Integrity: Maintain signal integrity for both analog and digital signals by using short traces, proper PCB layout practices, and, if necessary, shielding for analog inputs to minimize noise.

- Power Management: Assure a clean and reliable power supply for the AD5592RBRUZ. To cut down on noise, use decoupling capacitors near the power pins.

- Thermal Management: Although AD5592RBRUZ is designed for low power consumption, consider thermal aspects in high precision applications or when operating in a confined space.

By carefully implementing the AD5592RBRUZ in a sensor data acquisition system and addressing these design considerations, developers can create highly efficient, precise, and versatile control and monitoring solutions suitable for a wide range of applications.
