Analog Devices Inc. AD1974YSTZ

Part No.:: AD1974YSTZ

Manufacturer:: Analog Devices Inc.

Package:: 48-LQFP

Datasheet:: AD1974YSTZ.pdf

Description:: IC ADC/AUDIO 24BIT 192K 48LQFP

In Stock:: 2003

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

AD1974YSTZ Specifications

Package/Case:
48-LQFP
Packaging:
Tray
Series:
-
ProductStatus:
Active
Type:
ADC, Audio
NumberofChannels:
4
Resolution(Bits):
24 b
SamplingRate(PerSecond):
192k
DataInterface:
SPI
VoltageSupplySource:
Analog and Digital
Voltage-Supply:
3V ~ 3.6V
OperatingTemperature:
-40°C ~ 105°C
MountingType:
Surface Mount

AD1974YSTZ this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including AD1974YSTZ price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for AD1974YSTZ to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

AD1974YSTZ information

Views：

AD1974YSTZ Typical application Circuitry

AD1974YSTZ

The AD1974YSTZ is a high-performance, 4-channel analog-to-digital converter (ADC) designed specifically for audio applications. It features 24-bit resolution, a high dynamic range, and low distortion, making it suitable for professional audio recording, digital mixing consoles, and multi-channel audio systems.

Application Example: Multi-Channel Audio Recording System

1. Analog Input Connection: Connect the analog inputs (AIN1-AIN4) of the AD1974YSTZ to the output of microphone preamplifiers or other audio sources. These inputs will be converted to digital signals by the ADC.

2. Digital Audio Output Interface: Interface the digital audio outputs (SDATA1-SDATA4) with the input of a digital signal processor (DSP) or a computer for further processing and recording. Utilize the I2S or TDM interface for transmitting the digital audio data.

3. Clock Synchronization: Provide a stable master clock to the MCLK pin to ensure synchronous operation of the ADC. The LRCLK and BCLK pins should be connected to the appropriate clock signals for the chosen audio interface format.

4. Power Supply and Grounding: Supply power to the AD1974YSTZ by connecting the AVDD pin to an analog +3.3V power supply and the DVDD pin to a digital +3.3V power supply. Connect the AGND and DGND pins to their respective ground planes.

When designing a circuit with the AD1974YSTZ, consider the following:

- Signal Integrity: Keep analog and digital signal paths separate and well-shielded to minimize crosstalk and interference.

- Power Isolation: Use separate power supply lines and ground planes for the analog and digital sections to prevent digital noise from contaminating the analog audio signals.

- Clock Quality: Use a low-jitter clock source for the MCLK input to improve audio quality and reduce sampling artifacts.

- Configuration and Control: The AD1974YSTZ can be configured via hardware pins or a serial control interface. Ensure that the device is properly configured for the desired audio interface format and sampling rate.

By integrating the AD1974YSTZ into a multi-channel audio recording system, high-quality digital conversion of audio signals can be achieved, enabling precise recording and playback in studio or live sound environments.
