TDK Corporation ACH32C-104-T001

Part No.:: ACH32C-104-T001

Manufacturer:: TDK Corporation

Package:: 1206 (3216 Metric), 3 PC Pad

Datasheet:: ACH32C-104-T001.pdf

Description:: FILTER LC(T) 0.1UF SMD

In Stock:: 3350

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

ACH32C-104-T001 Specifications

Package/Case:
1206 (3216 Metric), 3 PC Pad
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
ACH
ProductStatus:
Obsolete
Type:
Low Pass
FilterOrder:
3rd
Technology:
LC (T-Type)
NumberofChannels:
1
Center/CutoffFrequency:
-
AttenuationValue:
-25dB @ 3.5MHz ~ 200MHz
Resistance-Channel(Ohms):
0.002
Current:
6 A
Values:
C = 0.1µF
ESDProtection:
No
OperatingTemperature:
-40°C ~ 125°C
Applications:
General Purpose
Voltage-Rated:
50V
MountingType:
Surface Mount
Size/Dimension:
1206 (3216 Metric), 3 PC Pad
