Name: 74LVC1G08GV,125
Brand: Nexperia USA Inc.
SKU: 74LVC1G08GV,125
Price: 2.40 USD
Availability: InStock
Rating: 5 (2 reviews)

Any Feature, including a modified Existing Feature, that is not an Existing Feature.

Cart ( )

lmages are for reference only See Product Specifications

Nexperia USA Inc. 74LVC1G08GV,125

Part No.:: 74LVC1G08GV,125

Manufacturer:: Nexperia USA Inc.

Package:: SC-74A

Datasheet:: 74LVC1G08GV,125.pdf

Description:: IC GATE AND 1CH 2-INP SC74A

In Stock:: 1655

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74LVC1G08GV,125 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74LVC
ProductStatus:
Active
LogicType:
AND Gate
NumberofCircuits:
1
NumberofInputs:
2
Features:
-
Voltage-Supply:
1.65V ~ 5.5V
Current-Quiescent(Max):
4 µA
Current-OutputHighLow:
32mA, 32mA
LogicLevel-Low:
0.7V ~ 0.8V
LogicLevel-High:
1.7V ~ 2V
MaxPropagationDelay@VMaxCL:
4ns @ 5V, 50pF
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount

74LVC1G08GV,125 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including 74LVC1G08GV,125 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for 74LVC1G08GV,125 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

74LVC1G08GV,125 information

Views：

74LVC1G08GV,125 Typical application Circuitry

74LVC1G08GV,125

74LVC1G08GV,125 is an AND gate with a single 2-input. By using a logical AND function, this chip only outputs a high signal when both of its inputs are high.

Application Scenarios:

1. Digital logic circuits.

2. Signal gating.

3. Input condition checking for microcontrollers.

4. Industrial control systems where multiple conditions or signals need to be combined.

Parameter Characteristics:

- Voltage range: 1.65V to 5.5V.

- Low power consumption.

- High noise immunity.

- Propagation delay: approximately 3.5 ns at 3.3V.

- Package: SC-74A.

Circuit Connection for Digital Logic Circuit:

1. Power Supply Connection: Connect a power supply within the range of 1.65V to 5.5V to pin 5 (VCC) of the 74LVC1G08GV,125.

2. Ground Connection: Connect pin 4 (GND) to the circuit's ground.

3. Input Connection: Connect the first logical signal to pin 1 (A1) and the second logical signal to pin 2 (A2) of the 74LVC1G08GV,125.

4. Output Connection: Connect pin 3 (Y) to the next stage of the circuit that requires the ANDed signal.

5. Unused Inputs: If any inputs are unused, they should be tied to the ground to prevent any erratic behavior due to floating inputs.

Design Considerations:

1. Input Compatibility: The input signals must be compatible with the voltage levels specified for the 74LVC1G08GV,125.

2. Stable Power Source: It's crucial to have a stable power source that operates within the given voltage range.

3. Load Characteristics: The output load should not exceed the driving capability of the chip.

4. Signal Integrity: To preserve signal integrity, appropriate termination and impedance matching are required.

In conclusion, the 74LVC1G08GV,125 is a flexible chip that can be applied in a range of situations where signal gating or logical AND operations are needed. Attention to voltage levels, power supply stability, load characteristics, and signal integrity is crucial to achieve optimal performance from this chip.
