Nexperia USA Inc. 74LVC14AD-Q100J

Part No.:: 74LVC14AD-Q100J

Manufacturer:: Nexperia USA Inc.

Package:: 14-SO

Datasheet:: 74LVC14AD-Q100J.pdf

Description:: IC INVERT SCHMITT 6CH 1-INP 14SO

In Stock:: 3141

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74LVC14AD-Q100J Specifications

Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q100, 74LVC
ProductStatus:
Active
LogicType:
Inverter
NumberofCircuits:
6
NumberofInputs:
1
Features:
Schmitt Trigger
Voltage-Supply:
1.2V ~ 3.6V
Current-Quiescent(Max):
40 µA
Current-OutputHighLow:
24mA, 24mA
LogicLevel-Low:
0.12V ~ 0.8V
LogicLevel-High:
1V ~ 2V
MaxPropagationDelay@VMaxCL:
6.4ns @ 3.3V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

74LVC14AD-Q100J this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including 74LVC14AD-Q100J price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for 74LVC14AD-Q100J to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

74LVC14AD-Q100J information

Views：

74LVC14AD-Q100J Typical application Circuitry

74LVC14AD-Q100J

The 74LVC14AD-Q100J is a specialized variant of the 74LVC14A logic chip, tailored for automotive applications, indicating its compliance with the Q100 quality standard for automotive electronics.

Application Scenarios

The 74LVC14AD-Q100J finds its use in various automotive applications where digital signal processing is required. This includes engine control units (ECUs), automotive sensor signal conditioning, and communication interfaces where signal integrity is critical under the harsh conditions of automotive environments.

Parameter Features

- Wide Operating Voltage Range: Supports 1.65V to 5.5V, enabling it to fit into various automotive electrical systems.

- High Noise Immunity: The Schmitt trigger inputs provide enhanced tolerance to noisy environments, a common scenario in automotive applications.

- Extended Temperature Range: Designed to operate over the automotive temperature range, ensuring reliability under extreme conditions.

- Low Power Consumption: Essential for automotive applications where energy efficiency is a priority.

Specific Application Circuit Design: Automotive Sensor Signal Conditioning

In designing a circuit with the 74LVC14AD-Q100J for automotive sensor signal conditioning, several critical aspects must be meticulously addressed.

- Sensor Signal Input: Initially, connect the output from an automotive sensor, which may exhibit signal noise, to an input pin of the 74LVC14AD-Q100J (for example, pin 1).

- Clean Signal Output: The corresponding output pin (e.g., pin 2 for pin 1 input) will provide a cleaner version of the input signal, thanks to the Schmitt trigger's noise filtering capabilities.

- Power Supply Considerations: Ensure that the Vcc pin (pin 14) is connected to a suitable power source within the 1.65V to 5.5V range, appropriate for the automotive electrical environment.

- Ground Connection: The GND pin (pin 7) must be properly grounded to ensure circuit stability and to minimize noise.

- Capacitive Decoupling: A decoupling capacitor should be placed close to the Vcc pin to filter out power supply noise, which is particularly important in the electrically noisy automotive environment.

Design Considerations

When integrating the 74LVC14AD-Q100J into automotive electronics, several considerations must be kept in mind:

- Environmental Robustness: The design must account for the chip's ability to withstand the automotive environment's temperature variations and vibrations.

- Electrical Interference: Automotive environments are notoriously noisy. It is crucial to ensure that the circuit minimizes susceptibility to electromagnetic interference (EMI).

- Power Supply Stability: Given the fluctuations in automotive power systems, ensuring a stable power supply to the chip is vital for reliable operation.

- Signal Integrity: Care must be taken to maintain signal integrity, considering the long wire runs and complex electrical systems in vehicles.

By adhering to these guidelines, the 74LVC14AD-Q100J can be effectively used in automotive applications, ensuring that digital signals are processed reliably and efficiently, even in the demanding conditions typical of automotive environments.
