Nexperia USA Inc. 74HCT08D-Q100,118

Part No.:: 74HCT08D-Q100,118

Manufacturer:: Nexperia USA Inc.

Package:: 14-SO

Datasheet:: 74HCT08D-Q100,118.pdf

Description:: IC GATE AND 4CH 2-INP 14SO

In Stock:: 3049

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74HCT08D-Q100,118 Specifications

Packaging:
Tape & Reel (TR)
Series:
Automotive, AEC-Q100, 74HCT
ProductStatus:
Active
LogicType:
AND Gate
NumberofCircuits:
4
NumberofInputs:
2
Features:
-
Voltage-Supply:
4.5V ~ 5.5V
Current-Quiescent(Max):
2 µA
Current-OutputHighLow:
4mA, 4mA
LogicLevel-Low:
0.8V
LogicLevel-High:
2V
MaxPropagationDelay@VMaxCL:
24ns @ 4.5V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

74HCT08D-Q100,118 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including 74HCT08D-Q100,118 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for 74HCT08D-Q100,118 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

74HCT08D-Q100,118 information

Views：

74HCT08D-Q100,118 Typical application Circuitry

74HCT08D-Q100,118

The 74HCT08D-Q100,118 is a high-speed Si-gate CMOS device. It is part of the 74HCT family and operates as a quad 2-input AND gate. This means that for each gate, it outputs a high level when both of its inputs are at a high level.

Application Scenarios for 74HCT08D-Q100,118:

This IC can be utilized in various digital circuits, such as:

- Signal processing units

- Microcontrollers and microprocessors

- Data communication devices

- Automotive applications due to its Q100 qualification

Parameter Features of 74HCT08D-Q100,118:

- Supply voltage range: 2.0 V to 6.0 V

- Propagation delay: approximately 8 ns

- Low power consumption

- High noise immunity

- Output drive capability: 4 mA at 5 V

Example of Application Circuit:

Let's consider a scenario where 74HCT08D-Q100,118 is used to drive an LED based on the status of two toggle switches. The steps for wiring the circuit are as follows:

1. Voltage Supply:

- Connect Pin 14 (VCC) to a 5 V power supply.

- Connect Pin 7 (GND) to the ground.

2. Input Connections:

- Attach a toggle switch to Pin 1 (A1), acting as the first input.

- Attach another toggle switch to Pin 2 (B1), acting as the second input.

3. Output Connection:

- Connect Pin 3 (Y1) to a 220-ohm resistor.

- The resistor's other terminal needs to be attached to the LED's anode.

- Lastly, connect the LED's cathode to the ground.

In this setup, the LED will light up when both toggle switches are turned ON, sending a HIGH signal to both inputs of the first AND gate, resulting in a HIGH output at Pin 3. This HIGH output will cause the LED to turn ON.

Design Considerations:

When creating a circuit with 74HCT08D-Q100,118, consider the following:

1. Voltage Levels:

- Ensure that the supply voltage stays within the specified range of 2.0 V to 6.0 V.

2. Input and Output Currents:

- The output current should not surpass the IC's maximum drive capability of 4 mA at 5 V.

3. Protection:

- Implement a resistor in series with the LED to regulate the current and prevent any potential damage to the LED.

4. Noise Immunity:

- Despite the 74HCT08D-Q100,118 having high noise immunity, it is recommended to place the IC away from high-frequency devices to prevent interference.

In summary, the 74HCT08D-Q100,118 is a versatile IC that can be applied in a variety of digital circuits. By carefully considering the required voltage levels, input and output currents, protective measures, and noise immunity, a robust and efficient circuit can be created.
