NXP USA Inc. 74HCT08D/C118

Part No.:: 74HCT08D/C118

Manufacturer:: NXP USA Inc.

Package:: 14-SO

Datasheet:: 74HCT08D/C118.pdf

Description:: IC GATE AND 4CH 2-INP 14SO

In Stock:: 3627

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74HCT08D/C118 Specifications

Packaging:
Bulk
Series:
74HCT
ProductStatus:
Active
LogicType:
AND Gate
NumberofCircuits:
4
NumberofInputs:
2
Features:
-
Voltage-Supply:
4.5V ~ 5.5V
Current-Quiescent(Max):
2 µA
Current-OutputHighLow:
4mA, 4mA
LogicLevel-Low:
0.8V
LogicLevel-High:
2V
MaxPropagationDelay@VMaxCL:
24ns @ 4.5V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

74HCT08D/C118 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including 74HCT08D/C118 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for 74HCT08D/C118 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

74HCT08D/C118 information

Views：

74HCT08D/C118 Typical application Circuitry

74HCT08D C118

The 74HCT08D/C118 is a quad 2-input AND gate IC. This means it has four independent AND gates, each with two inputs. It belongs to the High-Speed CMOS logic family, which provides a combination of high speed, low power consumption, and high noise immunity.

Applications for 74HCT08D/C118:

This chip can be utilized in various scenarios, such as:

- Digital signal processing units.

- Control circuits in microprocessors and microcontrollers.

- Data communication devices.

- Logic buffer for digital circuits.

Example Application Circuit:

Consider a scenario where 74HCT08D/C118 is employed to control an LED based on the status of two switches. The step-by-step instructions are:

1. Powering the IC:

- Connect pin 14 (VCC) to a 5V power supply.

- Connect pin 7 (GND) to the ground of the circuit.

2. Connecting the Inputs:

- Connect switch 1 to pin 1 (A1), which acts as the first input.

- Connect switch 2 to pin 2 (B1), which acts as the second input.

3. Connecting the Output:

- Connect pin 3 (Y1) to the resistor.

- Attach the resistor's other end to the LED's anode.

- Attach the LED's cathode to the ground.

When both switches are closed, pins 1 and 2 will receive a HIGH signal, resulting in a HIGH signal at pin 3. This will turn on the LED.

Design Considerations:

When designing a circuit with 74HCT08D/C118, consider the following:

1. Voltage Levels:

- Make sure the supply voltage is within the range of 2.0 V to 6.0 V to prevent damage to the IC.

2. Output Current:

- Ensure the output current does not exceed the chip's maximum drive capability of 4 mA at 5 V.

3. Protection:

- Implement protection mechanisms like resistors to limit the current flowing through the LED.

4. Noise Immunity:

- Keep the IC away from high-frequency devices to prevent interference, although 74HCT08D/C118 is known for its high noise immunity.

In summary, 74HCT08D/C118 is a versatile IC that can be utilized in various digital circuits. Taking into account the necessary voltage levels, output currents, protective measures, and noise immunity will result in a circuit that is both efficient and reliable for the desired application.
