Nexperia USA Inc. 74HC86DB,112

Part No.:: 74HC86DB,112

Manufacturer:: Nexperia USA Inc.

Package:: 14-SSOP

Datasheet:: 74HC86DB,112.pdf

Description:: IC GATE XOR 4CH 2-INP 14SSOP

In Stock:: 75948

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74HC86DB,112 Specifications

Packaging:
Tube,Tube
Series:
74HC
ProductStatus:
Obsolete
LogicType:
XOR (Exclusive OR)
NumberofCircuits:
4
NumberofInputs:
2
Features:
-
Voltage-Supply:
2V ~ 6V
Current-Quiescent(Max):
2 µA
Current-OutputHighLow:
5.2mA, 5.2mA
LogicLevel-Low:
0.5V ~ 1.8V
LogicLevel-High:
1.5V ~ 4.2V
MaxPropagationDelay@VMaxCL:
20ns @ 6V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

74HC86DB,112 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including 74HC86DB,112 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for 74HC86DB,112 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

74HC86DB,112 information

Views：

74HC86DB,112 Typical application Circuitry

74HC86DB,112

74HC86DB,112 is a quad 2-input exclusive OR (XOR) gate chip. This high-speed CMOS device finds its usage in digital systems where the comparison of two signals is required.

Applications:

- Arithmetic circuits

- Parity generators and checkers

- Data processing units

- Digital systems for error detection and correction

Parameter Features:

- Low power dissipation

- High noise immunity

- Operating voltage range: 2.0V to 6.0V

- Propagation Delay Time: Approximately 10 ns at VCC = 5V

Application Scenario – Parity Checker:

1. Setting up the Power Supply:

- Connect 74HC86DB,112 pin 14 (VCC) to a 5V power supply.

- Connect 74HC86DB,112 pin 7 (GND) to the ground.

2. Input Connections:

- Connect the 74HC86DB,112 two input signals to be compared to pins 1A & 1B, 2A & 2B, 3A & 3B, and 4A & 4B respectively.

3. Output Connections:

- Connect pins 1Y, 2Y, 3Y, and 4Y to the LEDs or any other indicating device to visualize the output.

4. Testing the Circuit:

- Apply various high- and low-signal combinations to the inputs, then watch the LEDs' output. A high output will indicate an odd number of high inputs, thus a parity error.

Design Considerations:

1. Voltage Levels: Make sure that the input signals' voltage levels fall within the 74HC86DB,112 operational voltage range.

2. Output Load: Make sure that the output load connected to the chip is within its drive capabilities.

3. Protection from Static Discharge: Take necessary precautions to protect the chip from static discharge during handling and assembly.

In conclusion, 74HC86DB,112 is an essential component in digital electronics for comparing two signals and generating an output based on their similarity or difference. Careful consideration of voltage levels, output load, and protection from static discharge is necessary to ensure optimal performance of the chip in a circuit.
