Application Scenarios:
- Connecting multiple sensors to a single data acquisition (DAQ) input in scientific instruments.
- Multiplexing several audio signals in consumer electronics.
- Routing control signals in industrial automation systems.
Parameter Features:
- Wide operating voltage range from 2 V to 6 V.
- Low ON resistance for efficient signal transmission.
- High OFF impedance for effective isolation between channels.
- ESD protection.
Circuit Example - Scientific Instrument:
In this example, we will demonstrate how to use 74HC4067PW,118 to connect multiple sensors to a single DAQ input in a scientific instrument.
1. Power Supply Connection:
- Connect VCC (pin 24) to a 5 V power supply.
- Connect GND (pin 12) to the circuit ground.
2. Sensor Connections:
- Connect the 74HC4067PW,118 outputs of up to 16 different sensors to the inputs S0 to S15 (pins 1 to 15 and 17 to 23).
- Connect the 74HC4067PW,118 common output to the DAQ input through pin 16 (COM).
3. Control Signals:
- Connect the digital control signals from a microcontroller to the address inputs A0 to A3 (pins 20 to 23) to select the desired sensor channel.
- Connect the enable input E (pin 19) to the microcontroller to enable/disable the multiplexer.
4. Data Acquisition:
- Use the control signals to select the desired sensor channel and route its output to the DAQ input for data acquisition.
Design Considerations:
- Check to see if the sensor output levels are within the chip's operational range.
- Implement proper filtering and signal conditioning to maintain data integrity.
- Consider the timing requirements of the data acquisition system to ensure accurate data sampling.
Conclusion:
74HC4067PW,118 is a versatile chip that offers an efficient solution for applications requiring the routing of multiple signals through a single channel. By carefully considering the circuit connections and design requirements, reliable and accurate data acquisition can be achieved in a scientific instrument.
