Nexperia USA Inc. 74HC4053D-Q100,118

Part No.:: 74HC4053D-Q100,118

Manufacturer:: Nexperia USA Inc.

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: 74HC4053D-Q100,118.pdf

Description:: IC MUX/DEMUX TRPL 2CH 16SOIC

In Stock:: 2446

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74HC4053D-Q100,118 Specifications

Package/Case:
16-SOIC (0.154, 3.90mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q100
ProductStatus:
Active
SwitchCircuit:
SPDT
Multiplexer/DemultiplexerCircuit:
2:1
NumberofCircuits:
3
On-StateResistance(Max):
120Ohm
Channel-to-ChannelMatching(ΔRon):
6Ohm
Voltage-SupplySingle(V+):
2V ~ 10V
Voltage-SupplyDual(V±):
±1.5V ~ 5V
SwitchTime(TonToff)(Max):
31ns, 29ns
-3dbBandwidth:
170MHz
ChargeInjection:
-
ChannelCapacitance(CS(off)CD(off)):
3.5pF
Current-Leakage(IS(off))(Max):
100nA
Crosstalk:
-60dB @ 1MHz
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
