Nexperia USA Inc. 74HC4051PW-Q100,11

Part No.:: 74HC4051PW-Q100,11

Manufacturer:: Nexperia USA Inc.

Package:: 16-TSSOP (0.173, 4.40mm Width)

Datasheet:: 74HC4051PW-Q100,11.pdf

Description:: IC MUX/DEMUX 8CH ANLG 16TSSOP

In Stock:: 2612

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74HC4051PW-Q100,11 Specifications

Package/Case:
16-TSSOP (0.173, 4.40mm Width)
Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
Automotive, AEC-Q100
ProductStatus:
Active
SwitchCircuit:
-
Multiplexer/DemultiplexerCircuit:
8:1
NumberofCircuits:
1
On-StateResistance(Max):
120Ohm
Channel-to-ChannelMatching(ΔRon):
6Ohm
Voltage-SupplySingle(V+):
2V ~ 10V
Voltage-SupplyDual(V±):
±1.5V ~ 5V
SwitchTime(TonToff)(Max):
51ns, 42ns
-3dbBandwidth:
180MHz
ChargeInjection:
-
ChannelCapacitance(CS(off)CD(off)):
3.5pF
Current-Leakage(IS(off))(Max):
400nA
Crosstalk:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
