Nexperia USA Inc. 74HC139D,653

Part No.:: 74HC139D,653

Manufacturer:: Nexperia USA Inc.

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: 74HC139D,653.pdf

Description:: IC DECODER/DEMUX 1 X 2:4 16SO

In Stock:: 145

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74HC139D,653 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74HC
ProductStatus:
Active
Type:
Decoder/Demultiplexer
Circuit:
1 x 2:4
IndependentCircuits:
2
Current-OutputHighLow:
5.2mA, 5.2mA
VoltageSupplySource:
Single Supply
Voltage-Supply:
2V ~ 6V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
