Toshiba Semiconductor and Storage 74HC138D

Part No.:: 74HC138D

Manufacturer:: Toshiba Semiconductor and Storage

Package:: 16-SOIC (0.154, 3.90mm Width)

Datasheet:: 74HC138D.pdf

Description:: IC DECODER 1 X 3:8 16SOIC

In Stock:: 301

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74HC138D Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74HC
ProductStatus:
Active
Type:
Decoder/Demultiplexer
Circuit:
1 x 3:8
IndependentCircuits:
1
Current-OutputHighLow:
5.2mA, 5.2mA
VoltageSupplySource:
Single Supply
Voltage-Supply:
2V ~ 6V
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount
