NXP USA Inc. 74HC125D,652

Part No.:: 74HC125D,652

Manufacturer:: NXP USA Inc.

Package:: 14-SOIC (0.154, 3.90mm Width)

Datasheet:: 74HC125D,652.pdf

Description:: IC BUFFER DVR TRI-ST QD 14SOIC

In Stock:: 3342

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74HC125D,652 Specifications

Package/Case:
14-SOIC (0.154, 3.90mm Width)
Packaging:
Bulk
Series:
74HC
ProductStatus:
Active
LogicType:
Buffer, Non-Inverting
NumberofElements:
4
NumberofBitsperElement:
1
InputType:
-
OutputType:
3-State
Current-OutputHighLow:
7.8mA, 7.8mA
Voltage-Supply:
2V ~ 6V
OperatingTemperature:
-40°C ~ 125°C (TA)
MountingType:
Surface Mount
