Nexperia USA Inc. 74HC04DB,118

Part No.:: 74HC04DB,118

Manufacturer:: Nexperia USA Inc.

Package:: 14-SSOP

Datasheet:: 74HC04DB,118.pdf

Description:: IC INVERTER 6CH 1-INP 14SSOP

In Stock:: 3275

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74HC04DB,118 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®
Series:
74HC
ProductStatus:
Obsolete
LogicType:
Inverter
NumberofCircuits:
6
NumberofInputs:
1
Features:
-
Voltage-Supply:
2V ~ 6V
Current-Quiescent(Max):
2 µA
Current-OutputHighLow:
5.2mA, 5.2mA
LogicLevel-Low:
0.5V ~ 1.8V
LogicLevel-High:
1.5V ~ 4.2V
MaxPropagationDelay@VMaxCL:
14ns @ 6V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

74HC04DB,118 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including 74HC04DB,118 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for 74HC04DB,118 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

74HC04DB,118 information

Views：

74HC04DB,118 Typical application Circuitry

74HC04DB,118

74HC04DB,118 represents a hex inverter integrated circuit. Like other inverter chips, it takes a digital input and produces the opposite digital output.

Applications:

1. Logic inversion: Wherever there's a need to convert a logic HIGH to LOW or vice versa.

2. Oscillators: With feedback loops, the 74HC04DB,118 can be part of simple oscillators.

3. Reset circuits: For debouncing or generating a reset pulse.

4. Signal buffering: Providing buffering while also inverting the signal.

Characteristics:

- Logic Family: High-Speed CMOS (74HC).

- Supply Voltage Range: Typically between 2V to 6V.

- Propagation Delay Time: It is quite fast, fitting for high-speed applications.

- Output Current: It has a decent output drive capability suitable for driving other CMOS inputs.

Application Example: Oscillator Circuit:

Components:

1. 74HC04DB,118 IC

2. Resistor (1MΩ)

3. Capacitor (10nF)

Steps:

1. Powering the IC: Attach pin 14 (Vcc) of the 74HC04DB,118 to your positive voltage source (e.g., 5V) and pin 7 (GND) to the ground.

2. Setting up the Oscillator: Connect one end of the resistor to pin 1 (input of the first inverter) and the other end to pin 2 (output of the same inverter).

3. Adding Capacitance: Attach one leg of the capacitor to pin 2 (output) and the other leg to the ground.

4. Output: The oscillating signal will now be available at pin 2.

Points to Ponder:

- Stability: The oscillator's frequency is determined by the resistor and capacitor's values. Adjust them as required.

- Noise Susceptibility: Long leads and breadboards can introduce noise. Use short leads and proper PCB layout for stability.

- Bypass Capacitor: As with most ICs, a 0.1µF capacitor should be placed between Vcc and GND near the 74HC04DB,118 to filter out noise.

- Unused Inputs: Don't leave inputs floating. Connect all unused input pins either to Vcc or GND to ensure stable operation.

When designing with 74HC04DB,118, it's paramount to always consider the specific needs of your application and the external components required to make the chip function as desired. This versatile chip, when used correctly, can be an invaluable asset in various digital circuits.
