Nexperia USA Inc. 74ALVC164245DGG,51

Part No.:: 74ALVC164245DGG,51

Manufacturer:: Nexperia USA Inc.

Package:: 48-TFSOP (0.240, 6.10mm Width)

Datasheet:: 74ALVC164245DGG,51.pdf

Description:: IC TRNSLTR BIDIRECTIONAL 48TSSOP

In Stock:: 3268

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74ALVC164245DGG,51 Specifications

Packaging:
Tube
Series:
74ALVC
ProductStatus:
Obsolete
TranslatorType:
Voltage Level
ChannelType:
Bidirectional
NumberofCircuits:
2
ChannelsperCircuit:
8
Voltage-VCCA:
1.5 V ~ 3.6 V
Voltage-VCCB:
1.5 V ~ 5.5 V
InputSignal:
-
OutputSignal:
-
OutputType:
Tri-State, Non-Inverted
DataRate:
-
OperatingTemperature:
-40°C ~ 125°C (TA)
Features:
-
MountingType:
Surface Mount
