Nexperia USA Inc. 74AHC1G08GW-Q100,1

Part No.:: 74AHC1G08GW-Q100,1

Manufacturer:: Nexperia USA Inc.

Package:: 5-TSSOP

Datasheet:: 74AHC1G08GW-Q100,1.pdf

Description:: IC GATE AND 1CH 2-INP 5TSSOP

In Stock:: 3660

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

74AHC1G08GW-Q100,1 Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
74AHC
ProductStatus:
Active
LogicType:
AND Gate
NumberofCircuits:
1
NumberofInputs:
2
Features:
-
Voltage-Supply:
2V ~ 5.5V
Current-Quiescent(Max):
1 µA
Current-OutputHighLow:
8mA, 8mA
LogicLevel-Low:
0.5V ~ 1.65V
LogicLevel-High:
1.5V ~ 3.85V
MaxPropagationDelay@VMaxCL:
7.9ns @ 5V, 50pF
OperatingTemperature:
-40°C ~ 125°C
MountingType:
Surface Mount

74AHC1G08GW-Q100,1 this integrated circuit is available in factory sealed anti static packs. at icwhale.com. Please read product page below detail information. including 74AHC1G08GW-Q100,1 price, data-sheet, in-stock availability, technical difficulties. Also. Quickly Enter the access of compare listing to find out replaceable electronic parts. If you want to retrieve comprehensive data for 74AHC1G08GW-Q100,1 to optimize the supply chain (including cross references, life-cycle, parametric, counterfeit risk, obsolescence managements forecasts), please contact to our Tech-supports team.

Purchase in icwhale.com

There is no doubt that you may place an order without registering to icwhale.com.

We strongly suggest you sign in our shop before purchasing as you can track your order real-time tracking.

Means of Payment in icwhale.com

For your convenience, we support multiple payment methods in USD, including PayPal, Credit Card, wire transfer. and Alipay.

RFQ (Request for Quotations) in icwhale.com

It is recommended to acquire for quotations to get the latest prices and inventories about the parts.

Our sales will reply to your request by email within 24 hours.

Warm reminder

1. You'll receive an order information email in your email inbox. (Please remember to check the spam folder if you didn't hear from us).

2. Since inventories and prices may fluctuate to some extent, the sales manager is going to reconfirm the order and let you know if there are any updates.

Shipping & Handling

Shipping fee starts at $35, but some countries will exceed $35. For example (South Africa, Brazil, India, Pakistan, Israel, etc.)

The basic freight (for package ≤0.5kg or corresponding volume) depends on the time zone and countries.

Shipping Method

Currently, our products are shipped through DHL, FedEx, SF, UPS and China Post.

Order Tracking for International Orders

Once your order has been shipped, the tracking number will be sent to the email address registered to your account. This information can also be viewed when logged into your account in the "my account" page.

74AHC1G08GW-Q100,1 information

Views：

74AHC1G08GW-Q100,1 Typical application Circuitry

74AHC1G08GW-Q100,1

The 74AHC1G08GW-Q100,1 is an advanced high-speed CMOS single 2-input AND gate integrated circuit, tailored for automotive and high-reliability applications. This device combines the benefits of CMOS technology with specifications to meet stringent automotive industry requirements, making it suitable for a wide array of applications that demand low power consumption, high speed, and robustness in challenging environments.

Application Scenario: Automotive Safety Systems

A notable application of the 74AHC1G08GW-Q100,1 is within automotive safety systems, where reliability and precision are paramount. In such a context, it can be utilized to integrate signals from various sensors to trigger safety mechanisms, such as airbag deployment or automatic braking, under specific conditions.

Parameter Features

- Wide Voltage Range: It operates efficiently within a 2.0V to 5.5V range, accommodating various automotive power systems.

- High-Speed with Low Power Consumption: The 74AHC1G08GW-Q100,1 ensures rapid signal processing while minimizing energy usage, crucial in battery-powered and energy-efficient automotive systems.

- Robustness for Automotive Use: Engineered to withstand the rigorous conditions of automotive environments, including temperature fluctuations and vibrations.

- Output Drive Capacity: Capable of driving multiple inputs, allowing for the integration of complex logic circuits without the need for additional components.

Detailed Circuit Connection: Signal Integration for Airbag Deployment

- Identify Input Signals: Connect input signals from acceleration sensors (indicating a collision) to pin 1, and from a rollover sensor to pin 2 of the 74AHC1G08GW-Q100,1. These sensors are crucial for determining conditions that warrant airbag deployment.

- Power Supply Configuration: Link the vehicle's power system to pin 5 (VCC) for the 74AHC1G08GW-Q100,1, ensuring it matches the device's operational voltage range. Connect the ground (GND) to pin 4.

- Output to Safety Mechanism: The output from pin 3 is directed towards the airbag control unit. A high signal, indicating both sensors have triggered, will initiate the deployment sequence.

- Ensure Signal Stability: Incorporate appropriate pull-up or pull-down resistors at the inputs to maintain signal integrity and avoid false triggering due to floating inputs.

- Noise Suppression: Given the automotive environment's electrical noise, deploying a decoupling capacitor near the VCC and GND pins is vital for stabilizing the supply voltage and filtering out interference.

Circuit Design Considerations

- Voltage Compatibility: Confirm the compatibility of the 74AHC1G08GW-Q100,1 with the automotive power supply to prevent operational issues or damage.

- Reliability in Harsh Conditions: Design the circuit with robust components and protection mechanisms to ensure functionality amidst automotive stresses such as temperature extremes and mechanical vibrations.

- Power Efficiency: While the 74AHC1G08GW-Q100,1 is designed for low power consumption, overall system power management is crucial, especially in energy-sensitive automotive applications.

- Minimizing Electromagnetic Interference (EMI): Automotive systems are susceptible to EMI, which necessitates careful layout and shielding techniques to preserve signal integrity and comply with automotive electromagnetic compatibility standards.

Integrating the 74AHC1G08GW-Q100,1 into automotive safety systems exemplifies leveraging state-of-the-art technology to enhance vehicle safety and reliability. Attention to detail in circuit design, along with an understanding of the device's capabilities and automotive requirements, enables the development of sophisticated safety features that protect passengers effectively.
