Renesas Electronics America Inc 70V24L20PFGI

Part No.:: 70V24L20PFGI

Manufacturer:: Renesas Electronics America Inc

Package:: 100-LQFP

Datasheet:: 70V24L20PFGI.pdf

Description:: IC SRAM 64KBIT PARALLEL 100TQFP

In Stock:: 2673

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

70V24L20PFGI Specifications

Package/Case:
100-LQFP
Packaging:
Tray
Series:
-
ProductStatus:
Active
MemoryType:
Volatile
MemoryFormat:
SRAM
Technology:
SRAM - Dual Port, Asynchronous
MemorySize:
64Kb (4K x 16)
MemoryInterface:
Parallel
ClockFrequency:
-
WriteCycleTime-WordPage:
20ns
AccessTime:
20 ns
Voltage-Supply:
3V ~ 3.6V
OperatingTemperature:
-40°C ~ 85°C (TA)
MountingType:
Surface Mount
