onsemi 1SMB5924BT3G

Part No.:: 1SMB5924BT3G

Manufacturer:: onsemi

Package:: DO-214AA, SMB

Datasheet:: 1SMB5924BT3G.pdf

Description:: DIODE ZENER 9.1V 3W SMB

In Stock:: 3438

Quantity:: Add To Cart

For more detailed including pricing and shipping

: Quick response, quick quotation

: Flash shipment, no worries after sales

: Original channel, guarantee of the authentic products

Please send RFQ , we will respond immediately.

Purchase and inquiry

1SMB5924BT3G Specifications

Packaging:
Tape & Reel (TR),Cut Tape (CT),Digi-Reel®,Bulk
Series:
RoHS:
RoHS
Tolerance:
±5%
Part Status:
Active
Power - Max:
3 W
Mounting Type:
Surface Mount
Impedance (Max) (Zzt):
4 Ohms
Operating Temperature:
-65°C ~ 150°C
Voltage - Zener (Nom) (Vz):
9.1 V
Current - Reverse Leakage @ Vr:
5 µA @ 7 V
Voltage - Forward (Vf) (Max) @ If:
1.5 V @ 200 mA
