Cart ( )| Datasheet | Photo | Mfr. Part # | Stock | Price | Quantity | Packaging | Series | ProductStatus | Color | Wavelength | Current-Test | Voltage-Forward(Vf)(Typ) | Lumens/Watt@Current-Test | Current-Max | LuminousFlux@Current/Temperature | Temperature-Test | ViewingAngle | MountingType | Size/Dimension |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Datasheet |
|
SML-LX1610RGBW/ALED TITANBRITE RGB 626/525/470 |
3335 | 8.95 |
Add To CartInquiry Now |
Tube | TitanBrite™ | Active | Red, Green, Blue (RGB) | 626nm Red, 525nm Green, 470nm Blue | 300mA Red, 350mA Green, 350mA Blue | 2.1V Red, 3.5V Green, 3.5V Blue | 40 lm/W Red, 20 lm/W Green, 7 lm/W Blue | 300mA Red, 350mA Green, 350mA Blue | 25lm Red, 25lm Green, 8lm Blue | 25°C | 110° | Surface Mount | TO-252-3, DPak (2 Leads + Tab), SC-63 |
|
Datasheet |
|
SML-LX1610SIC/ALED TITANBRITE RED 625NM SMD |
3239 | 0.00 |
Add To CartInquiry Now |
Tube | TitanBrite™ | Active | Red | 625nm (Typ) | 350mA | 2.1V | - | 350mA | - | 25°C | 110° | Surface Mount | TO-252-3, DPak (2 Leads + Tab), SC-63 |
|
Datasheet |
|
SSP-LX6144A2UPCLED LUXLED GREEN 525NM SMD |
2567 | 0.00 |
Add To CartInquiry Now |
Tube | LuxLED™ | Obsolete | Green | 525nm (Typ) | 120mA | 3.4V | 7 lm/W | 120mA | 3lm (Typ) | 25°C | 10° | Surface Mount | 6-SMD, Flat Leads |
|
Datasheet |
|
SSP-LX6144A3SCLED LUXLED YELLOW 590NM SMD |
3128 | 0.00 |
Add To CartInquiry Now |
Tube | LuxLED™ | Obsolete | Yellow | 590nm (Typ) | 120mA | 2.4V | 17 lm/W | 120mA | 5lm (Typ) | 25°C | 10° | Surface Mount | 6-SMD, Flat Leads |
|
Datasheet |
|
SSP-LX6144A6UCLED LUXLED RED 626NM SMD |
3808 | 0.00 |
Add To CartInquiry Now |
Tube | LuxLED™ | Obsolete | Red | 626nm (Typ) | 120mA | 2.4V | 10 lm/W | 120mA | 3lm (Typ) | 25°C | 10° | Surface Mount | 6-SMD, Flat Leads |
|
Datasheet |
|
SSP-LX6144A7UCLED LUXLED BLUE 470NM SMD |
3656 | 0.00 |
Add To CartInquiry Now |
Tube | LuxLED™ | Obsolete | Blue | 470nm (Typ) | 120mA | 3.4V | 5 lm/W | 120mA | 2lm (Typ) | 25°C | 10° | Surface Mount | 6-SMD, Flat Leads |
|
Datasheet |
|
SSP-LX6144C2UPCLED LUXLED GREEN 525NM SMD |
2856 | 0.00 |
Add To CartInquiry Now |
Tube | LuxLED™ | Obsolete | Green | 525nm (Typ) | 120mA | 3.4V | 7 lm/W | 120mA | 3lm (Typ) | 25°C | 30° | Surface Mount | 6-SMD, Flat Leads |
|
Datasheet |
|
SSP-LX6144C3SCLED LUXLED YELLOW 590NM SMD |
3312 | 0.00 |
Add To CartInquiry Now |
Tube | LuxLED™ | Obsolete | Yellow | 590nm (Typ) | 120mA | 2.4V | 17 lm/W | 120mA | 5lm (Typ) | 25°C | 30° | Surface Mount | 6-SMD, Flat Leads |
| |
|
SSP-LX6144C6UCLED LUXLED RED 626NM SMD |
3991 | 0.00 |
Add To CartInquiry Now |
Tube | LuxLED™ | Obsolete | Red | 626nm (Typ) | 120mA | 2.4V | 10 lm/W | 120mA | 3lm (Typ) | 25°C | 30° | Surface Mount | 6-SMD, Flat Leads |
|
Datasheet |
|
SSP-LX6144D2UPCLED LUXLED GREEN 525NM SMD |
2019 | 0.00 |
Add To CartInquiry Now |
Tube | LuxLED™ | Obsolete | Green | 525nm (Typ) | 120mA | 3.4V | 7 lm/W | 120mA | 3lm (Typ) | 25°C | 100° | Surface Mount | 6-SMD, Flat Leads |
